Waveplate for telecom

This waveplate is compact, expoxy free true zero order waveplate used for fiber optics communication. The half waveplate rotate the polarization direction, while the quarter waveplate convert linearly polarized light into a circular (elliptical) or vice versa.


Features of Waveplate for telecom

- Expoxy Free
- Large Angle Acceptance
- Low Temperature Sensitivity
- Wide Spectral Bandwidth

Specifications of Telecom Waveplate

Dimension Tolerance: +0.0/-0.1mm
Parallelism <1 arc second
Surface Quality: 20-10
Wavefront Distortion: λ/8@633nm
Retardation Tolerance: <λ/300 wave
Coating: AR-coated R<0.1%

Waveplate for Telecom Order Information

Optocity offer large volume waveplates for telecom, special mark is availbe. Volume discount apply.


1. λ/4 Waveplate for Telecom

WPS102Q λ/4 2x2mm Waveplate for Telecom


WPS105Q λ/4 5x5mm Waveplate for Telecom


WPS109Q λ/4 9x9mm Waveplate for Telecom


Additional message: qty. wavelength, holder...

2. λ/2 Waveplate for Telecom

WPS102Q λ/2 2x2mm Waveplate for Telecom


WPS105Q λ/2 5x5mm Waveplate for Telecom


WPS109Q λ/2 9x9mm Waveplate for Telecom


Additional message: qty. wavelength, coating...


Inquiry Waveplate for telecom

Your E-mail: Subject: Message with contact information: Enter webcode: 2795 - Thank you! We'll reply very soon.
